Use MCP servers in VS Code (Preview)

Model Context Protocol (MCP) is an open standard that enables AI models to interact with external tools and services through a unified interface. In VS Code, MCP support enhances GitHub Copilot's agent mode by allowing you to connect any MCP-compatible server to your agentic coding workflow. This article guides you through setting up MCP servers and using tools with agent mode in Visual Studio Code.

Note

MCP support in agent mode in VS Code is currently in preview.

What is MCP?

Model Context Protocol (MCP) provides a standardized way for AI models to discover and interact with external tools, applications, and data sources. When you enter a chat prompt to a language model with agent mode in VS Code, the model can invoke various tools to perform tasks like file operations, accessing databases, or calling APIs in response to your request.

MCP follows a client-server architecture:

MCP clients (like VS Code) connect to MCP servers and request actions on behalf of the AI model
MCP servers provide one or more tools that expose specific functionalities through a well-defined interface
The Model Context Protocol (MCP) defines the message format for communication between clients and servers, including tool discovery, invocation, and response handling

For example, a file system MCP server might provide tools for reading, writing, or searching files and directories. GitHub's MCP server offers tools to list repositories, create pull requests, or manage issues. MCP servers can run locally on your machine or be hosted remotely, and VS Code supports both configurations.

By standardizing this interaction, MCP eliminates the need for custom integrations between each AI model and each tool. This allows you to extend your AI assistant's capabilities by simply adding new MCP servers to your workspace. Learn more about the Model Context Protocol specification.

Supported MCP capabilities

VS Code supports local standard input/output (stdio) and server-sent events (sse) for MCP server transport. Currently of the 3 primitives (tools, prompts, resources), servers can only provide tools to Copilot's agent mode. The list and descriptions of tools can be updated dynamically using list changed events. VS Code provides servers with the current workspace folders using roots (spec).

Finding MCP servers

MCP's official server repository is a great starting point for reference, official, and community-contributed servers that showcase MCP's versatility. You can explore servers for various functionalities, such as file system operations, database interactions, and web services.

MCP is still a relatively new standard, and the ecosystem is rapidly evolving. As more developers adopt MCP, you can expect to see an increasing number of servers and tools available for integration with your projects.

Add an MCP server

To add an MCP server to your workspace, follow these steps (see below for how to add a server to your user settings):

Configure an MCP server in the .vscode/mcp.json file in your workspace to share configurations with project collaborators. Make sure to avoid hardcoding sensitive information like API keys and other credentials by using input variables or environment files.

Create a .vscode/mcp.json file in your workspace and select the Add Server button to add a template for a new server. VS Code provides IntelliSense for the MCP server configuration file.

Alternatively, run the MCP: Add Server command from the Command Palette and provide the server information to add a new MCP server configuration. Choose Workspace Settings to create the .vscode/mcp.json file in your workspace if it doesn't already exist.

The following example shows how to configure a Perplexity MCP server, where VS Code prompts you for the API key when the server starts. Learn more about the Configuration format.
```
{
  // 💡 Inputs are prompted on first server start, then stored securely by VS Code.
  "inputs": [
    {
      "type": "promptString",
      "id": "perplexity-key",
      "description": "Perplexity API Key",
      "password": true
    }
  ],
  "servers": {
    // https://github.com/ppl-ai/modelcontextprotocol/
    "Perplexity": {
      "type": "stdio",
      "command": "npx",
      "args": ["-y", "@modelcontextprotocol/server-perplexity-ask"],
      "env": {
        "PERPLEXITY_API_KEY": "${input:perplexity-key}"
      }
    }
  }
}
```
Optionally, specify the server in the mcp VS Code user settings to enable the MCP server across all workspaces.

If you use the MCP: Add Server command from the Command Palette, choose User Settings to add a new MCP server configuration in user settings.
VS Code can automatically detect and reuse MCP servers that you defined in other tools, such as Claude Desktop. Enable auto-discovery with the chat.mcp.discovery.enabled setting.
Run the MCP: List Servers command from the Command Palette to view and manage the configured MCP servers.

Configuration format

Use the following JSON configuration format to define MCP servers.

The "servers": {} field holds the list of MCP servers, and follows Claude Desktop's configuration format.

Specify the server name as the key and provide the server configuration as the value. VS Code shows the server name in the MCP server list.

Provide the following fields in the server configuration. You can use predefined variables in the server configuration, for example to refer to the workspace folder (${workspaceFolder}).

Connect with stdio:

Field	Description	Examples
`type`	Server connection type.	`"stdio"`
`command`	Command to start the server executable.	`"npx"`,`"node"`, `"python"`, `"docker"`
`args`	Array of arguments passed to the command.	`["server.py", "--port", "3000"]`
`env`	Environment variables for the server.	`{"API_KEY": "${input:api-key}"}`
`envFile`	Path to an `.env` from which to load additional environment variables.	`"${workspaceFolder}/.env"`

Connect with sse:

Field	Description	Examples
`type`	Server connection type.	`"sse"`
`url`	URL of the server (for `"type": "sse"`).	`"http://localhost:3000"`
`headers`	HTTP headers for the server (for `"type": "sse"`).	`{"API_KEY": "${input:api-key}"}`

The "inputs": [] field lets you define custom placeholders for configuration values, avoiding hardcoding sensitive information.

VS Code prompts you for these values when the server starts for the first time, and securely stores them for subsequent use. To avoid showing the typed value, set the password field to true.

Learn more about how to configure input variables in VS Code.

Configuration example

The following code snippet shows an example MCP server configuration that specifies three servers and defines an input placeholder for the API key.

// Example .vscode/mcp.json
{
  // 💡 Inputs will be prompted on first server start,
  //    then stored securely by VS Code.
  "inputs": [
    {
      "type": "promptString",
      "id": "perplexity-key",
      "description": "Perplexity API Key",
      "password": true
    }
  ],
  "servers": {
    // https://github.com/ppl-ai/modelcontextprotocol/
    "Perplexity": {
      "type": "stdio",
      "command": "docker",
      "args": ["run", "-i", "--rm", "-e", "PERPLEXITY_API_KEY", "mcp/perplexity-ask"],
      "env": {
        "PERPLEXITY_API_KEY": "${input:perplexity-key}"
      }
    },
    // https://github.com/modelcontextprotocol/servers/tree/main/src/fetch
    "fetch": {
      "type": "stdio",
      "command": "uvx",
      "args": ["mcp-server-fetch"]
    },
    "my-remote-server": {
      "type": "sse",
      "url": "http://api.contoso.com/sse",
      "headers": { "VERSION": "1.2" }
    }
  }
}

Use MCP tools in agent mode

Once you have added an MCP server, you can use the tools it provides in agent mode. To use MCP tools in agent mode:

Open the Chat view (⌃⌘I (Windows, Linux Ctrl+Alt+I)), and select Agent mode from the dropdown.
Select the Tools button to view the list of available tools.

Optionally, select or deselect the tools you want to use. You can search tools by typing in the search box.

Tip
You can also directly reference a tool in your prompt by typing # followed by the tool name. You can do this in all chat modes (ask, edit, and agent mode).
You can now enter a prompt in the chat input box and notice how tools are automatically invoked as needed.

By default, when a tool is invoked, you need to confirm the action before it is run. This is because tools might run locally on your machine and might perform actions that modify files or data.

Use the Continue button dropdown options to automatically confirm the specific tool for the current session, workspace, or all future invocations.
Optionally, verify and edit the tool input parameters before running the tool.

Select the chevron next to the tool name to view its details and input parameters. You can edit the input parameters before running the tool.

Managing tools

Run the MCP: List Servers command from the Command Palette to view the list of configured MCP servers.

MCP server list

When you select a server, you can start, stop, or restart the server. You can also view the server configuration and server logs to diagnose issues.

Tip

When you open the .vscode/mcp.json file, VS Code shows commands to start, stop, or restart a server directly from the editor.

MCP server configuration with lenses to manage server.

Command-line configuration

You can also use the VS Code command-line interface to add an MCP server to your user profile or to a workspace.

To add an MCP server to your user profile, use the --add-mcp command line option, and provide the JSON server configuration in the form {\"name\":\"server-name\",\"command\":...}.

code --add-mcp "{\"name\":\"my-server\",\"command\": \"uvx\",\"args\": [\"mcp-server-fetch\"]}"

URL handler

VS Code also includes a URL handler that you can use to install an MCP server. To form the URL, construct an obj object in the same format as you would provide to --add-mcp, and then create the link by using the following logic:

// For Insiders, use `code-insiders` instead of `code`
const link = `code:mcp/install?${encodeURIComponent(JSON.stringify(obj))`;

This link can be used in a browser, or opened on the command line, for example via xdg-open $LINK on Linux.

Troubleshooting

When VS Code encounters an issue with an MCP server, it shows a error indicator in the Chat view.

Select the error notification in the Chat view, and then select the Show Output option to view the server logs. Alternatively, run MCP: List Servers from the Command Palette, select the server, and then choose Show Output.

MCP Server Error Output

Create an MCP server

VS Code has all the tools you need to develop your own MCP server. While MCP servers can be written in any language that can handle stdout, the MCP's official SDKs are a good place to start:

Frequently asked questions

Can I control which MCP tools are used?

Yes, you have several options to control which tools are active:

Select the Tools button in the Chat view when in agent mode, and toggle specific tools on/off as needed.
Add specific tools to your prompt by using the Add Context button or by typing #.
For more advanced control, you can use .github/copilot-instructions.md to fine-tune tool usage.

Related resources

04/03/2025
